Atmospheric air and moisture are a continuous threat to the efficient operations of your equipment and machinery as the same carries with it fine particles. When a hydraulic oil reservoir or gearbox breathes, air containing water vapour is ingested into the system. Temperature fluctuations will cause this water vapour to condense which can speed up the oxidation of the fluid and lead to damage in the system.
The desiccant filter replaces the standard dust cap or breather cap on equipment, offering better filtration to protect against even the smallest particulates that destroy the effectiveness of your machinery and cause downtime and costly repairs.
Desiccant filters air through lightweight breather filters that combine air filtration and moisture absorption. While inhaling air, these filters pass it through a fine 2-micron absolute-rated filter, cleaning it of all possible solid particulates and drying the air as it passes through the drying agent. As moisture is absorbed, the drying agent will gradually change from orange to dark green or blue to pink based on the type of drying agent used. The color change is easy to identify, allowing you to quickly replace the breather and maintain the cleanliness of the fluid reservoir.
With the most durable polycarbonate casing, an impact-resistant standpipe that creates optimal and even airflow, quality check-valve technology, and more, our inline desiccant filter solutions offer protection against moisture and particulate contamination for almost any application in your systems and equipment.
Product Features of Desiccant Filter
- Air flow rates up to 5,000 l/min
- Air Filter rating: 2 µm
- Operating temperature : -30 °C to +100 °C
- Fastening using a flange or screw connection
- Multiple threaded connections variant available
- Versions may be equipped with visual/electrical contamination indicators
User Benefits of Desiccant Filter
- Standard versions are economically priced and have to be replaced fully upon time of replacement
- Re-buildable / Replaceable versions available wherein only Silica gel beads and spin-on breather filter have to be replaced and not complete assembly
- Unmistakable water removal.
- Select breathers with dual check valves option available, this gives a longer service life for the breather
- Achieve total systems cleanliness when used in conjunction with more robust particulate filtration ensuring your equipment is protected from all forms of contamination.
By utilizing our desiccant air filter solutions, you can achieve a new level of efficiency and protection for your equipment.
